copy of SikaEmaco® T 1100 TIX - Noxan.pl

copy of SikaEmaco® T 1100 TIX

Fast-setting, rapid-hardening, shrinkage-compensating, steel-fiber-reinforced, flowable high-strength repair mortar. For horizontal concrete surfaces exposed to high dynamic loads and impact.

SikaEmaco® T 1400 FR is a one-component, flowable repair mortar with very high strength, featuring fast setting and rapid strength development. The product is classified as R4 in accordance with EN 1504-3.

SikaEmaco® T 1400 FR is a ready-to-use mortar containing sulphate-resistant Portland cement (HSR LA), hydraulic binders, sands with optimized grading, galvanized steel fibers, polymer fibers (PAN – polyacrylonitrile), and additives that ensure rapid strength gain also at temperatures below 0°C, high durability, and low drying shrinkage.

After mixing with water, a flowable consistency is obtained, which can be easily placed manually in layers with a thickness of 10–150 mm.

Applications of SikaEmaco® T 1400 FR:

  • large-area repairs of horizontal concrete pavements exposed to extreme traffic loads,
  • repairs of damaged joints,
  • bedding of small and large manhole frames using formwork,
  • streamlining renovation works in facilities and on transport routes with heavy traffic,
  • indoor and outdoor use,
  • use at low temperatures,
  • applications requiring very short downtime.

Approximate consumption: to prepare 1 m3 of fresh mortar, approx. 2035 kg of SikaEmaco® T 1400 FR is required.

One 25 kg bag and 3 l of water yields approx. 12.3 l of mortar (actual yield depends on the amount of mixing water).

Delivery: 3–5 business days.

Packaging
zł16,113.00 brutto

zł13,100.00 netto

zł13.43 brutto za 1 kg
keyboard_arrow_down

Ask about the product

Fast return to service

Rapid strength gain - return to service after approx. 2 hours (at +20°C)

Easy application

Easy application

Flowable consistency facilitates application

Flowable consistency - facilitates application

Key properties:

Application and execution conditions

  • easy application,
  • flowable consistency
    facilitating application,
  • after adding gravel
    application in thicker layers is possible,
  • can be used at temperatures
    below zero down to -5°C
  • Very high plasticity
    thanks to special steel fibers

Strength and crack reduction

  • rapid strength gain
    return to service after approx. 2 hours (at +20°C),
  • high strength
    early and final,
  • low shrinkage,
  • minimized susceptibility to cracking
    thanks to shrinkage compensation and steel-fiber reinforcement

Durability and service resistances

  • excellent adhesion
    and durability,
  • excellent resistance
    to freeze/thaw cycles,
  • resistance to high dynamic loads and impact,
  • high resistance to hydrocarbons
  • very good slip resistance,
    also in wet conditions
  • Two to three times higher flexural strength
    than standard repair mortars

Structural protection and compliance

  • very good reinforcement protection
    thanks to very low water absorption and good carbonation resistance,
  • CE marking in accordance with EN 1504-3
    R4-class cement mortar for structural and non-structural repair of concrete in buildings and civil engineering works, compliant with EN 1504-3:2005, with a declaration of performance based on a factory production control conformity certificate issued by a notified body certifying factory production control, bearing the CE mark

Technical information

Compressive strength

  +20°C1) +5°C2) -5°C3)
2 hours ≥ 30 MPa – –
3 hours – ≥ 15 MPa ≥ 8 MPa
4 hours ≥ 50 MPa ≥ 20 MPa ≥ 12 MPa
1 day ≥ 70 MPa ≥ 55 MPa ≥ 50 MPa
7 days ≥ 85 MPa ≥ 65 MPa ≥ 70 MPa
28 days ≥ 100 MPa ≥ 85 MPa ≥ 90 MPa

1) Curing temperature, water and powder: +20°C

2) Curing temperature, water and powder: +5°C

3) Curing temperature: -5°C; water and powder temperature: +20°C

Modulus of elasticity in compression

Value 40 000 MPa
Standard (EN 13412)

Flexural strength

1 day ≥ 15 MPa
7 days ≥ 20 MPa
28 days ≥ 25 MPa

Shrinkage

28 days ≤ 0.300 mm/m

Pull-off strength

Adhesion to concrete / mortar 28 days ≥ 3.0 MPa
Adhesion to concrete after freeze–thaw cycles, mortar 28 days (50 cycles, de-icing salts exposure) ≥ 3.0 MPa

Reaction to fire

Class A1
Standard (EN 13501-1)

Capillary absorption

28 days ≤ 0.1 kg·m-2·h-0.5

Carbonation resistance

28 days meets dk ≤ that of control concrete

Service temperature

Range -30°C to +80°C

Ring test

Cracking tendency No cracks (up to 180 days)

Application

Mixing ratio

Water amount 2.7 to 3.2 l of water per 25 kg bag

Layer thickness

Repair / installation mortar 10 - 150 mm

Product temperature

Minimum / Maximum Minimum +5°C / Maximum +30°C

Ambient temperature

Minimum / Maximum Minimum -5°C / Maximum +30°C

Substrate temperature

Minimum / Maximum Minimum 0°C / Maximum +30°C

Pot life

Time ~ 20 minutes at +20°C

(higher temperatures shorten the pot life, and lower temperatures extend it)

Load-bearing capability

Light traffic (+20°C) ~ 60 minutes
Full load (+20°C) ~ 120 minutes

Fresh mortar density

Value ~ 2.28 g/cm3

Consumption

Consumption per 1 m3 of fresh mortar approx. 2035 kg of SikaEmaco® T 1400 FR
Yield from a 25 kg bag approx. 12.3 liters of mortar (with 3 l of water)
