Conductive Resin Static Guard 30-11 AS
Static Guard 30-11 AS is a two-component, water-based epoxy resin designed for creating a conductive intermediate layer in flooring systems requiring the dissipation of electrostatic charges.
It provides uniform electrical conductivity - resistance range 3–6 × 10³ Ω.
The resin is part of the Static Guard antistatic system - it ensures conductivity continuity between the earthing system, copper tapes and subsequent flooring layers. Static Guard 30-11 AS is applied under the self-levelling Static Guard 30-52 AS antistatic resin (see the system cross-section).
Static Guard 30-11 AS Conductive Resin contains no VOC or solvents. It is easy to mix and apply with a roller, and its shortened curing cycle supports the achievement of the final conductive properties of the floor.
Consumption: 0.15 kg/m² (per layer)
More information about Static Guard 30-11 AS resin.
Key properties:
Product characteristics
- water-based, two-component epoxy resin (2K),
- for use as a conductive intermediate layer in anti-static systems,
requiring classification in accordance with EN 1081 and EN 61340.
Conductive properties
- provides uniform electrical conductivity,
resistance range: 3 - 6 x 10³ Ω.
Safe application
- contains no Volatile Organic Compounds (VOC: 0 g/l),
or solvents - easy mixing and application,
with a roller, - shortened curing cycle,
supporting the achievement of final conductivity.
Application
- together with the Static Guard anti-static system,
in explosion hazard areas / EX zones, the automotive industry, laboratories, warehouses, the medical sector, etc.
Static Guard anti-static system:
| System type: | System per m2: | Coating thickness: | Cost per m2: |
|---|---|---|---|
| Self-levelling system: - applied with a rake - approx. 2 mm thick |
1-2 x 0.25 kg of HeavyBond 30-33 primer + 0.25 lm of NX1106 copper tape + 1-2 x 0.15 kg of Static Guard 30-11 AS Conductive Resin + 2 kg of Static Guard 30-52 AS Anti-static Resin |
approx. 2 mm | check cost |
The systems presented are general recommendations. Each project should be treated individually. In case of any doubts, please contact us so that we can select the right system for a specific problem.
Static Guard anti-static system cross-section:
Volatile Organic Compounds:
Static Guard 30-11 AS Conductive Resin
Volatile Organic Compounds content (VOC) - 0 g/l
* Information about the level of vapour emissions (VOC) during application and until the coating is fully cured.
Emission levels from A+ (very low) to C (high).
Additional information about Volatile Organic Compounds.
Documentation:
Documents
- Technical Data Sheet - detailed product properties and application method
- Safety Data Sheet - base - chemical, health & safety and transport information
- Safety Data Sheet - hardener - chemical, health & safety and transport information
System
- Static Guard system description - layer build-up, application and operating recommendations
